? Thin encapsulation with heat sink， efficient heat dissipation.
? Applicable to fluorescent lamp etc. cost-effective
? Rated power：0.2W
| Parameter | Symbol | Rating |
| Forward Current | IF | 35mA |
|
Pulse Forwards Current*2 |
IFP | 100mA |
|
Reverse Voltage |
VR |
5V |
|
Working Temperature |
TOPR |
-30~+85℃ |
|
Storage Temperature |
TSTG |
-40~+100℃ |
| Color | Part number | Color temp(K) | CRI Ra Min |
IF( mA) TEST |
Φv（l m） Typ. |
VF( V) Typ. |
IR(μA) Max*1 |
| Natural white | FM-T3528WNS-460R | 5600-6500 | 70 | 20 | 7.0 | 3.2 | 10 |
|
Neutral white |
FM-T3528WDS-460R-R70 | 3700-4200 | 70 | 20 | 6.5 | 3.2 | 10 |
|
Warm white |
FM-T3528WLS-460R-R70 |
2800-3200 |
70 |
20 | 6.0 | 3.2 | 10 |
